Bubble Padded Mailer Making Machine
Strength.Efficiency.Versatility.Convertibility.
Customization.Sustainability
The Topaz Bubble Mailer Machine is a high-performance device designed for medium-sized and big manufacturers that produces bubble envelopes in huge quantities. This kind of bubble mailer The machine stands out for its extremely high production efficiency and its capacity to quickly and widely switch up the variety of created goods. Although the modular structure permits any design, it is typically purchased with the most equipment to properly meet market demands.
One of the machine’s key features is that it was constructed using standardized components that can be found in almost every local market. This guaranties simple, affordable, and most importantly, quick access to spare parts. Professional maintenance departments will especially value this feature and the construction’s adaptability.
In addition to the standard configuration (a list of features below), it is possible to apply individual technical solutions indicated by the buyer because this machine is made for customers who already have experience in the industry and have developed their own habits and frequently their own technical solutions.Higher volumes can be produced using this equipment.
Overview
Kraft bubble wrap envelopes/envelopes with bubbles production machine, self-adhesive tape, and envelope pouch machine (self-sealing bubble wrap shipping mailer machine, such as envelope padded self-seal kraft bubble envelop machine; excellent for shipping; robust and lightweight; bubble wrap lining).
Air Bubble Padded Envelope: Craft paper is laminated to create the air bubble envelope. These are offered in different GSM and sizes to meet customer needs. Compact disks, floppy disks, and other delicate items are best protected by this product.
This particular machine is made especially for making kraft bubble envelopes. The bag method involves laminating Kraft paper with PE bubble film using hot roll bonding, molding composite materials using a fold forming apparatus, and cutting them into a standard composite bubble envelope after hot pressing the horizontal seal. The machine is a high-quality dedicated equipment bag that uses sophisticated motion control technology to unwind from the film material to cut molding. It is controlled by a computer system and comes out of the bag neatly and beautifully, with strong adhesion, dependable operation, and ease of understanding.
Features & Benefits
1.Work with COATED and UNCOATED PAPER,
2.Output up to 150-200 pieces/min
2.Work in a double web system (two envelopes per cycle) up to the H8 (285mm x 370mm) format (optionally up to K20 format)
3.Capability of working with pre-printed paper – system for switching between top and bottom web included in standard version
4.Ability to replace the bubble wrap without stopping the machine,
5.Double, rotary bubble wrap feeders (feeding the material in the machine’s axis or side-feeding for the purpose of limiting machine length)
6.Paper feeders (separately for upper and lower webs) with pneumatic paper roll lifters- max weight of paper rolls 700kg (optionally 1200 kg)
7.Web edge control systems – separate for each web (4x)
8.Tension control system separately for each web (4x)
9.Two double drive systems of the finished web (an innovative drive system with web’s tension adjustment, developed by us)
9.Belt conveyor for receiving envelopes with counting function (standard transporter length 4 meters)
Specifications
Download the latest product brochure in next section for more detailed information, contact us if further information is needed
Model:HJ-HEP-2-IN1-MAILER-1500P
Unwinding width: ≤1500mm
Unwinding diameter :≤1250mm
Size: 28000x2350x2280mm
Production Speed: 60-200 Pcs/min
Rated Power:75kw
Power Supply:220v-380v 50hz
Weight:14.5t
Machine loading of paper & release of paper rolls
Touchscreen control
Highly intelligent
Easy to operate
Online assistance available
Frequently Asked Questions
What materials can the machine process?
hey typically handle kraft paper, polyethylene (PE) plastic film, and metallized insulating films combined with co-extruded bubble cushioning layers.
Can it produce custom sizes?
Yes, most modern units feature programmable logic controllers (PLCs) and touch-screen HMI panels allowing operators to adjust bag lengths, widths, and sealing intervals.
